F2.5

F2.5


Our 72-cc 2.5-hp portable outboard is the smallest motor on our roster, but it still packs a punch. Completely redesigned, it’s even more portable, easier to store and clean burning.

  • Only 37 pounds (15” shaft model)
  • Available in 15” and 20” shaft lengths
SPECIFICATIONS
  • Weight *: 17 kg (37 lbs) - 20 kg (40lbs)
  • Full Throttle RPM Range: 5250 ~ 5750
  • Fuel Induction System: Carb
  • Recommended Engine Oil: Yamalube® 4M (See owner's manual)
  • Engine Type: 1 cyl
  • Displacement: 72cc
  • Bore x Stroke: 54 x 31.5 mm (2.13 x 1.24 in)
  • Prop Shaft Horsepower: 2.5hp at 5500 rpm
  • Alternator Output at W.O.T.: N/A
  • Compression Ratio: 8.8:1
  • Recommended Fuel: Octane 87
  • Recommended Fuel Filtration: N/A
  • C.A.R.B. Rating: 2-Star
  • Exhaust: Above Propeller
  • Intake: 2
  • Ignition: TCI
  • Spark Plug: CR6HSB
  • Starting System: Manual
  • Lubrication: Splash
  • Engine Oil Capacity: 0.35L
  • Recommended Cooling: Thermostatic Control
  • Ethanol Blend Limit: 10% Maximum
  • Gear Ratio: 2.01:1
  • Gear Shift: Forward, Neutral
  • Shaft Length: 15" - 20"
  • Degree of Tilt: 79°
  • Degree of Trim: -4° through +16°
  • Mounting Centers: N/A
  • Steering
  • Steering Angle (maximum): 360° from center, either direction
  • Warranty: Limited 3-Year Pleasure, 3-Year Government, 1-Year Commercial

*Weight refers to shortest shaft length, and is measured without motor oil, gearcase oil and propeller (except models 25 hp and under, which include a standard propeller). All Jet model weights include the jet pump assembly (weight estimated).

COMPATIBILITY

The 72-cc 2.5-hp portable is available with tiller handle control and F-N-R shifting. Explore compatible components below and contact your dealer for rigging expertise.

Compatible Controls:
Multi-Function Tiller Handle

Compatible Gauges:
Command Link and Analog Gauges

FEATURES & BENEFITS

Power and Performance:
Lightweight, Portable Power
Surprising Performance
Record Setting Fuel Efficiency

Convenience and Control:
Lightweight, Portable Power
Surprising Performance
Record Setting Fuel Efficiency

PORTABLES PACKED WITH

PERFORMANCE

They weigh as little as 37 pounds, but all offer impressive features like electronic ignition, thermostatic cooling and 180-degree steering.

RELIABILITY & DURABILITY

WET SUMP
A pressurized oil delivery system that incorporates a compact and durable oil pump to keep all of the moving parts of their Overhead Valve systems lubricated and running smoothly for maximum reliability.
