F8
Our 212-cc 8-hp portable outboard features 7.5 percent more displacement than its previous design. This SOHC two cylinder outboard delivers a nice balance of power, performance and portability for jon boats and inflatables. Its new, shorter tiller handle makes operation more comfortable, so you can make a whole day of it.
- Only 87 pounds
- Available in 15” and 20” shaft lengths
- Solid 6-amp alternator
SPECIFICATIONS
- Weight*: 39 kg (87 lbs) - 40 kg (89 lbs)
- Full Throttle RPM Range: 5000 ~ 6000
- Fuel Induction System: Carb
- Recommended Engine Oil: Yamalube® 4M (See owner's manual)
- Engine Type: 2 cyl
- Displacement: 212cc
- Bore x Stroke: 56 x 43mm (2.20 x 1.70 in.)
- Prop Shaft Horsepower: 8hp at 5500 rpm
- Alternator Output at W.O.T.: 6 Amp
- Compression Ratio: 9.4:1
- Recommended Fuel: Octane 87
- Recommended Fuel Filtration: Yamaha 10-Micron Fuel/Water Separating Filter (external)
- C.A.R.B. Rating: 3-Star
- Exhaust: Through Propeller
- Intake: 4
- Ignition: CDI Microcomputer
- Spark Plug: BR6HS-10
- Starting System: Manual
- Lubrication: Wet Sump
- Engine Oil Capacity: 0.8L
- Recommended Cooling: Thermostatic Control
- Ethanol Blend Limit: 10% Maximum
- Gear Ratio: 2.08:1
- Gear Shift: Forward, Neutral, Reverse
- Shaft Length: 15" - 20"
- Degree of Tilt: 71°
- Degree of Trim: -4° through +16°
- Mounting Centers: N/A
- Steering
- Steering Angle (maximum): 43° from center, either direction
- Warranty: Limited 3-Year Pleasure, 3-Year Government, 1-Year Commercial
*Weight refers to shortest shaft length, and is measured without motor oil, gearcase oil and propeller (except models 25 hp and under, which include a standard propeller). All Jet model weights include the jet pump assembly (weight estimated).
COMPATIBILITY
The 212-cc 8-hp portable is available with a shorter tiller handle for comfort. Explore compatible components below and contact your dealer for rigging expertise.
Compatible Controls:
Multi-Function Tiller Handle
Compatible Gauges:
Command Link and Analog Gauges
FEATURES & BENEFITS
Power and Performance:
Compact, Lightweight Design
Responsive Acceleration
Streamlined Intake
Convenience and Control:
Smart Evolution
Portability And Storage
Propeller Protection
RELIABILITY & DURABILITY
OPTIMAL OPERATION
A CDI Microcomputer Ignition monitors throttle position, engine speed and atmospheric conditions in order to precisely adjust ignition timing under all conditions for optimum ignition performance, ensuring smooth and reliable operation.
